HR 80121

type ST · family 1YP · 51.1 kV maximum anode voltage · 110° deflection · 3 windings · 410 g

Manufacturer equivalents (4)

DBTEC 125161 · FCC 136 · FE 6928 A 1 · SADFBTCC136-131 A

Possible substitutes

Parts of a similar design. A shortlist to check, not a recommendation.

HR 8592 · HR 8483 · HR 7424 · HR 7050 · HR 8675 · HR 8875 · HR 8778 · HR 8927 · HR 80120 · HR 6498

Fitted to (6)

SAMPO 9638 · SAMPO MONITOR · SANYO CPP 3250 TX · TEAC CTM 761 · TEAC CTM 761 ST · TEAC CTM 761 STN

Search this part in the full database
